Easy operation for end user
Operating structure divided into program management, operation and configuration.
Universal input via keypad
Smart technology with innovative operating concept.
Operator interface protected by Lexan front foil
This guarantees IP65 protection at the front.
Universal main input for the size to be controlled
Possibility to process different types of signals e.g. thermocouples, resistance thermometers, thermistors
Selection of the input typology
Only via the keypad, no shunts are required for adjustment.
Simplified programming procedure
Parameters are combined in function blocks
Simplified menu for entering the most frequently used parameters.
(depending on variation)
Alternatively we offer for all standard and special units, a unit equipment according to customer-specific specifications.
The control and regulation system is equipped according to your wishes and specifications.
Operation | via keypad |
Accuracy | better than 0.2% at nominal conditions |
Available protocols | MODBUS, RTU, CENCAL |
Configuration | via service interface |
Protection type at the front | IP 65 |
Voltage supply | AC 100 ... 240 V ±10% |
Current input | at 230 V: 52mA |
Power input | 50/60Hz, max. 12VA |
Operating / position temperature | 0 ...+50 °C / -20 … +70°C |
Climate resistance | 20…85%rF non-condensing |
Dimensions (B x H x T) | 48x48x129 mm |
Weight | Approx 210g |
|
