TECHNICAL EQUIPMENT

 (depending on variation)

• Simple menu-driven configuration without programming knowledge

• Programmer with 8 setpoints, 32 digital tracks, 99 programs

• 8 control zones with 8 PID parameter sets, 1 tolerance band and 2 limit values per zone

• 64 Alarms

• 8 Formulas

• 16 tolerance bands, 16 limit values

• SPS with 1600 instructions, 64 timers, programmable in AWL

• Self-optimization function to determine the optimal PID control parameters

• 5 analog value multiplexers

• User administration with max. 5 login levels

• Interfaces: 1 x Ethernet, 2 x USB, CAN master

• Interfaces I/O systems: STANGE SIOS or CAN (via CAN bus), up to 16 actual values, 16 analog outputs, 64 digital inputs, 64 digital outputs

• Memory: 512 MB Micro SD card for programs/configuration, 2 GB SD card for data logger (option)

• Actual value correction: Up to 5 correction points can be freely defined for each actual value
• Actual value filtering: Measurement value falsifications are filtered out with this function.

Alternatively we offer for all standard and special units, a unit equipment according to customer-specific specifications.
The control and regulation system is equipped according to your wishes and specifications.

Optional

• Interface modules (PROFINET, PROFIBUS): Interface for connecting a SE-702 as slave to a PROFIBUS system; master can be e.g. a SPS S7
• C-level control for controlling carburizing processes: Temperature and furnace atmosphere are controlled using a special formula for carbon calculation
• Humidity calculation
• Data logger for up to 16 values: The data logger records and stores all relevant process values and makes them accessible for evaluation.
• Creation of the system visualization
